Titan-84L – Precision Turned Part (Titans of CNC Lathe Series)
📝 Description:
Part Name: Titan-84L
Certification Path: Titans of CNC – Lathe Series
Software Used: SolidWorks (CAD) & SolidCAM (CAM)
Skills Demonstrated:

Lathe-specific modeling and setup

OD (Outer Diameter) and ID (Inner Diameter) profiling

Facing and grooving operations

Chamfers and radii transitions

G-code programming logic for turning processes

Simulation and verification of lathe toolpaths

About This Part:
Titan-84L is a foundational lathe project from the Titans of CNC Lathe Series. The part focuses on precision turning techniques, including facing, OD profiling, chamfering, and internal boring. This project allowed me to deepen my understanding of lathe toolpaths and machine setup, while reinforcing tight tolerances and clean edge transitions.

I programmed the part using SolidCAM’s lathe operations and verified the toolpaths through simulation. The G-code was then visualized in NC Viewer to ensure correct cutting sequences, tool changes, and work offsets. This project represents a key step in building my CNC lathe programming skills.

Deliverables Included:

SolidWorks model screenshots

SolidCAM toolpath simulation images

G-code snippets

Titans of CNC reference print

Certificate of completion
